TP-Link TL-SG1024D Unmanaged Gigabit Ethernet (10/100/1000) Grey

Brand: TP-Link
107.99 €
In Stock

Description

What This Product Does
The TL-SG1024D Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1024D can save power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.

TP-LINK Green Technology
This new generation TL-SG1024D Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.

High Performance
All 24 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1024D forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the tra­ffic congestion and make The TL-SG1024D work reliably. It’s a perfect choice to update your network to Gigabit while protecting your previous investment properly.

Easy to Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Specification

Data transmission
Forwarding rate
35.7 Mpps
Jumbo frames
10000
Jumbo frames support
MAC address table
8000 entries
Store-and-forward
Supported data transfer rates
10/100/100 Mbps
Switching capacity
48 Gbit/s
Design
LED indicators
Product colour
Grey
Rack mounting
Stackable
Features
Bandwidth
48 Gbit/s
Certification
FCC, CE, RoHS
Full duplex
Maximum data transfer rate
1 Gbit/s
Logistics data
Harmonized System (HS) code
85176990
Management features
Quality of Service (QoS) support
Switch type
Unmanaged
Network
10G support
No
Auto MDI/MDI-X
Auto-negotiation
Cable types supported
Cat3, Cat4, Cat5, Cat5e
Flow control support
Networking standards
IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Supported network protocols
CSMA/CD, TCP/IP
Operational conditions
Heat dissipation
46.44 BTU/h
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
32 - 104 °F
Storage relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-40 - 70 °C
Other features
AC input frequency
50 - 60 Hz
Connectivity LEDs
Y
Networking features
Gigabit Ethernet
Power requirements
100 - 240V, 50/60Hz
Packaging content
Rack mount kit
User guide
Packaging data
Cables included
AC
Package depth
400 mm
Package height
80 mm
Package type
Box
Package weight
1.95 kg
Package width
250 mm
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Connectivity technology
Wired
Gigabit Ethernet (copper) ports quantity
24
Power connector
DC-in jack
Power
AC input voltage
100 - 240 V
Power consumption (max)
13.62 W
Power source
AC
Power supply included
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Weight & dimensions
Depth
180 mm
Dimensions (WxDxH)
294 x 180 x 44 mm
Height
44 mm
Width
294 mm
