Description
No Configuration Needed Simply Plug and Play!With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is inserting a micro SIM card and turning on the router. It has never been easier than enjoy a fast, stable Wi-Fi on 4G LTE network.
Share Your 4G LTE NetworkTake full advantage of your cutting-edge 4G LTE network to download speed up to 150 Mbps. Share your 4G LTE network with multiple Wi-Fi devices and enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide.
Robust Parental ControlsIf you want to block harmful websites, set surfing time limits, check which sites your kids are using or just pause the internet, you can do it all.
Wi-Fi Where You Need ItEnjoy unconstrained convenience and versatility. MR100 has been tested in the field for years to ensure universal compatibility with 2 advanced LTE antennas to deliver a smooth connection. Simply plug in a micro SIM card and power on this elegant piece of device to utilize fast and stable Wi-Fi, whether you’re at home or working remotely.
Reliable Access for Up to 32 Devices SimultaneouslyEasily share a 3G/4G connection with up to 32 wireless devices, such as phones, tablets, and laptops, at the same time. 1 LAN ports stand ready to provide internet for wired devices like desktop computers.
Specification
Design
Antenna design
External
On/off switch
Product colour
Black
Reset button
Features
Certification
CE, RoHS
DHCP client
Ethernet LAN
Firmware upgradeable
Port forwarding
Receiver sensitivity
11g 54M: -74dBm
11n HT20: -71dBm
11n HT40: -67dBm
Wi-Fi Multimedia (WMM)/(WME)
Logistics data
Harmonized System (HS) code
85176990
Management features
Quality of Service (QoS) support
Wireless statistics
WPS push button
Mobile network
3G
4G
UMTS bands supported
850,900,2100 MHz
Network
3G standards
HSPA, UMTS
4G bands supported
800,900,1800,1900,2100,2300,2500,2600 MHz
4G standard
LTE-TDD & LTE-FDD
Cabling technology
10/100Base-T(X)
Dynamic DNS (DDNS)
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)
20 dBmW
Ethernet LAN (RJ-45) ports
2
Ethernet LAN data rates
10,100 Mbit/s
Ethernet LAN interface type
Fast Ethernet
Mobile network generation
4G
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port triggering
Security algorithms
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Supported network protocols
IPv4, IPv6
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
Wi-Fi band
Single-band (2.4 GHz)
Wi-Fi standards
802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wireless radio
Operational conditions
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
Storage relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-40 - 70 °C
Other features
Antennas quantity
2
Packaging content
AC adapter included
Quick installation guide
Packaging data
Cables included
LAN (RJ-45)
Package depth
161 mm
Package height
66 mm
Package weight
450 g
Package width
293 mm
Performance
Antenna connector type
N-type
Browser supported
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Memory card slot(s)
No
Power source type
DC
Product type
Tabletop router
Ports & interfaces
DC-in jack
USB port
No
Power
Output current
0.85 A
Output voltage
9 V
Protocols
DHCP server
Universal Plug and Play (UPnP)
Security
DMZ support
Firewall
IP address filtering
MAC address filtering
Schedule access
Stateful Packet Inspection (SPI)
Software
Linux operating systems supported
Windows operating systems supported
Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
System requirements
Mac operating systems supported
WAN connection
3G/4G USB modem compatibility
DSL WAN
Ethernet WAN
SIM card slot
WAN connection type
RJ-45
Weight & dimensions
Depth
114 mm
Height
36 mm
Width
154 mm
Wireless LAN features
Guest access
WLAN data transfer rate (max)
300 Mbit/s
