Description
Get powerful and reliable WiFi 6 connectivity for all your devices, even in high-density environments. Simplified enterprise-grade security and networking for small and medium sized business.
REMOTE CLOUD MANAGEMENTPlug-and-play set up and remote management of small business networks
NETWORK TOPOLOGYA single, holistic view of wired and wireless networks for further troubleshooting
HIGH-DENSITY WIFI MANAGEMENTDeep wireless management features with more tools to deploy small and large WiFi networks
Business-Level SecurityWPA3 for the highest level of WiFi connection security
8 Wireless Networks (SSIDs)Separate VLANs and WPA3 makes WAX630 the ideal network configuration for SMBs for security and manageability
Separate VLANsKeep admin, employee, visitor, HR, Finance department networks safely separated from each other
NETGEAR INSIGHT FOR VARSMulti-location & multi-tenant remote network management from a single pane-of-glass
Easy SetupSet up, configure, and manage with NETGEAR Insight
Remote ManagementRemote Cloud monitoring and management with NETGEAR Insight for single pane of glass management of all your Insight Managed devices. 1-Year Insight subscription included
Flexible MountingEasy to securely install on the wall of a suspended ceiling with the hardware included
Specification
Antenna
Antenna gain level (max)
4.3 dBi
Design
LED indicators
Placement
Ceiling, Wall
Product colour
White
Reset button
Features
2.4 GHz
5 GHz
Maximum data transfer rate
6000 Mbit/s
Maximum data transfer rate (2.4 GHz)
1200 Mbit/s
Maximum data transfer rate (5 GHz)
2400 Mbit/s
MIMO type
Multi User MIMO
Number of users
200 user(s)
Spread spectrum method
OFDM, OFDMA
Wi-Fi Multimedia (WMM)/(WME)
Logistics data
Harmonized System (HS) code
85176990
Management features
Web-based management
Network
Antenna type
Internal
Auto MDI/MDI-X
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
100,1000,2500 Mbit/s
MIMO
Networking standards
IEEE 802.11ax, IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Security algorithms
EAP-TLS, PEAP, SSL/TLS, TTLS, WPA, WPA2, WPA3
VLAN support
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Other features
Modulation
OFDM
Packaging content
Mounting kit
Quick start guide
Packaging data
Quantity per pack
1 pc(s)
Ports & interfaces
DC-in jack
Power
Output current
3.5 A
Output voltage
12 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Security
Auto Wireless Distribution System (WDS)
MAC address filtering
Remote Authentication Dial-In User Service (RADIUS)
Service Set Identifier (SSID) features
SSID broadcast, SSID broadcast on/off
Weight & dimensions
Depth
268.3 mm
Height
55.5 mm
Weight
956 g
Width
266.6 mm
