Description
Specification
Design
Product colour
Black
Rack capacity
1U
Rack mounting
Display
On Screen Display (OSD)
Features
Certification
CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4
FCC: Part 15 Subpart B
Maximum resolution
3840 x 2160 pixels
Number of users
128 user(s)
Throughput data rate
200 Mbit/s
Hard drive
HDD interface
SATA III
Maximum storage capacity
12 TB
Number of HDDs supported
2
Multimedia
Video formats supported
H.264, H.265
Network
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Supported network protocols
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Operational conditions
Operating temperature (T-T)
-10 - 55 °C
Storage relative humidity (H-H)
0 - 90%
Storage temperature (T-T)
-20 - 70 °C
Other features
Built-in processor
Packaging data
Package depth
433 mm
Package height
366 mm
Package weight
2.76 kg
Package width
141 mm
Performance
Alarm input channels
4
Alarm output channels
2
Backup function
HDMI output
Multi-screen
Number of motion detection zones
396
Operating system installed
Embedded LINUX
People counting
Playback controls
Playback modes
Backup selection, Digital zoom, Forward, Full screen, Next camera, Pause, Play, Previous camera, Repeat, Reverse, Shuffle, Speed Adjust, Stop
PTZ control
Recording modes
Continuous, Manual, Schedule, Stop
Recording time
120 min
Snapshot
Two-way talk
USB 2.0 ports quantity
1
Video input channels
4 channels
Video loss detection
Ports & interfaces
Audio RCA inputs
1
Audio RCA outputs
1
HDMI ports quantity
1
Internal SATA ports quantity
2
SATA revision
3.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
VGA (D-Sub) output ports
1
Power
Output current
2 A
Output voltage
48 V
Power consumption (typical)
9 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity
4
Power over Ethernet (PoE) power per port
25.5 W
Total Power over Ethernet (PoE) budget
50 W
Security
Video motion detection
Video
Bit rate
20000 Kbit/s
Weight & dimensions
Depth
282.4 mm
Height
53 mm
Weight
1.51 kg
Width
375 mm
